● Mark inspection vision (2D mark inspection) recognizes and recodes marks, broken and redundant mark strokes, and marks that are outside of the plastic seal.

● 3D5S can detect product size and integrity; it can also detect pin length, standoff height, offsets, pin width and pin spacing.

● In pocket vision (in tape) detects defective products (defects visible to the naked eye) such as broken, contaminated and cracked plastic seals.

● Product transfer: main turret has 24 vacuum pickheads.

● The vacuum pickheads have the function of shielding and automatic height correction.

● Can be connected to a variety of brands of tester, software independent property rights, the use of key switches, standard keyboard for operation and data input, with workstation interlock function.

● Orientation aligner: accurate positioning and commutation of the product, positioning tolerance ≤0.005mm, directional accuracy up to 0.1 degrees.

● Number of test stations：7(5+2QA) stations elastic pressure contact kelvin test station can complete the repeated test of the products to be taped, and the test accuracy is high.

● Packaging：TO252，dry run≥UPK=18k (no test or test marking times≤120ms).
